Winco 12kW Standby Generator
12kW LP / 10kW NG 120/240 Volts Single Phase EPA/CARB Emissions
The Winco 12kW Standby Generator fits home and commercial applications to keep the power on during an outage. Powered by a 993 cc Vanguard industrial V-twin engine, Winco generators provide years of reliable service. A prime power rating makes the generators suitable for off-grid and alternative energy applications for locations without utility power.
Winco ships the PSS12WH2W/F ready to run on propane, but the generator is field convertible to natural gas.
Winco PSS12WH2W/F Quick Look
| Engine | Honda GX690 688cc Heavy Duty V-Twin |
| Running Watts | 12kW LP / 10kW NG |
| No Load Sound Level | 65.2 dBA |
| Full Load Sound Level | 66.8 dBA |
| Frequency Regulation | +/- 5% |
| Voltage Regulation | +/- 5% |
| Total Harmonic Distortion | <5% |
| Alternator | Brushless Revolving Field 100% Copper Windings |
Winco 12kW Generator Features
- An American Company, Winco manufactures generators at its facility in LeCenter, Minnesota with modern engineering, fabrication, and assembly.
- Each generator is 100 percent load tested before it leaves the factory.
- DSE 3110 Controller provides operation and diagnostic information.
- Sure Flow Cooling system with three intakes to provide exceptional air flow and reduce heatsoak.
- Battery charge maintenance with a 1.5-Amp marine grade charger.
- Automatic Voltage Regulation at +/- 1 percent.
- 2/3 rotor pitch with 100% copper windings and brushless revolving field.
- Runs on propane or natural gas.
- USB Connectable.
Engine / Genset Protection
- Low oil pressure
- High oil temp
- Over/under speed
- Over/under voltage
- Under frequency
- Battery over/under voltage
The Winco Standby Generator includes a Winco 2-Year / 2000-Hour Limited Warranty. Honda covers the GX690 Engine under the Honda warranty.
Product Specifications
Model
Model Number; PSS12H2W/F
Manufacturer; Winco Generators
Made In USA; Yes
Rated Watts; 12kW Propane | 10kW Natural Gas
Rated Amps; 50 Amps Propane | 41 Amps Natural Gas
Voltage; 120/240 Volts Single Phase
Enclosure; Galvanealed Steel with Powder Coat Paint
UL Listed; UL-2200
Decibel Rating
- No Load – 65.2 dBA
- Full Load – 66.8 dBA
Type; Standby Generator
Features
Starting System; Automatic
Low Oil Alert; Yes – DSE3110 Controller
Mainline Breaker; 50 Amps
Hour Meter; Yes – DSE3110 Controller
Battery Requirement; 12-Volt Group 26 500 CCA
Weight; 484 Pounds
Dimensions; 48L x 32W x 36H Inches
Warranty Information
Consumer Warranty; Winco 2-Year/2000 Hour Limited Warranty
Commercial Warranty; Winco 2-Year/2000 Hour Limited Warranty
Engine
Engine Brand; Honda GX690 Heavy Duty
Engine Size; 688 cc V-Twin
Engine RPM; 3600 RPM
Cast Iron Sleeve; Yes
Cooling System; Air Cooled
Alternator
Alternator Type; Heavy-Duty 2-Pole Revolving Field
Frequency; 60 Hertz
Auto Voltage Regulation; Yes
Fuel
Fuel Type; Propane (LP) or Natural Gas (NG)
Fuel Gauge; No
NG Power Capacity; 12kW
LP Power Capacity; 10kW
NG Consumption @ Full Load; 190 Cubic Feet per Hour
LP Consumption @ Full Load; 2.1 Gallons per Hour
