Kohler CH395-3018 Command PRO Series OHV Engine, 2:1 Gear Reduction with Clutch, 9.5 Gross HP, 277cc, 0.87-inch Diameter Gear Box Shaft, Air-Cooled, 4-Cycle, Single Cylinder
Key Specifications
| BRAND | Kohler |
|---|---|
| MODEL NUMBER | CH395-3018 |
| WARRANTY | 3 Year Limited |
| SHIPPING WEIGHT | 73.4 |
| DISPLACEMENT | 277cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Horizontal |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | 2:1 with Clutch |
| CRANKSHAFT DIMENSIONS | .87″ x 2-21/32″ |
| CRANKSHAFT DIAMETER | .87″ |
| CRANKSHAFT LENGTH | 2-21/32″ |
| CRANKSHAFT KEYWAY WIDTH | 0.3″ |
| BEARING TYPE | Dual Ball |
| CYLINDERS | 1 |
| AIR CLEANER TYPE | Cyclonic Filter |
| OIL CAPACITY | 1.4 qt |
| LOW OIL SHUTDOWN | Yes |
| IGNITION SYSTEM | Electronic |
| NOTES | Engine Notes: |
